Ball-Type grease nipples type C (K3) DIN 3402
Ball-Type grease nipples type C (K3) DIN 3402
Straight version, zinc-plated steel.
UMETA ball-type nipples are suitable for all standard lubrication points, which have to be frequently lubricated in a reliably way. They are more and more often replaced by hyraulic-type grease nipples according to DIN 71412 due to their manifold application purposes.
In stock | Shipping within the Benelux within 24 hours
€ 0,81
GW
M 6x1.0
SW (mm)
9
L1 (mm)
18
L2 (mm)
5.5
WL (mm)
13
W
90°
In stock | Shipping within the Benelux within 24 hours
€ 0,81
GW
M 8x1.0
SW (mm)
9
L1 (mm)
18
L2 (mm)
5.5
WL (mm)
13
W
90°
In stock | Shipping within the Benelux within 24 hours
€ 0,86
GW
M 10x1.0
SW (mm)
11
L1 (mm)
18
L2 (mm)
5.5
WL (mm)
14
W
90°
Out of stock | Shipping within 2 weeks
€ 0,86
GW
1/8 GAS
SW (mm)
11
L1 (mm)
18
L2 (mm)
5.5
WL (mm)
14
W
90°
Out of stock | Shipping within 2 weeks
€ 1,29
GW
1/4 GAS
SW (mm)
14
L1 (mm)
22.5
L2 (mm)
6.5
WL (mm)
15
W
90°
| Article | GW | SW (mm) | L1 (mm) | L2 (mm) | WL (mm) | W | PU | Stock | Price | Order | ||
| 2304504 C | M 6x1.0 | 9 | 18 | 5.5 | 13 | 90° | 1 | In stock | Shipping within the Benelux within 24 hours | € 0,81 | |||
| 2304507 C | M 8x1.0 | 9 | 18 | 5.5 | 13 | 90° | 1 | In stock | Shipping within the Benelux within 24 hours | € 0,81 | |||
| 2304709 C | M 10x1.0 | 11 | 18 | 5.5 | 14 | 90° | 1 | In stock | Shipping within the Benelux within 24 hours | € 0,86 | |||
| 2304756 C | 1/8 GAS | 11 | 18 | 5.5 | 14 | 90° | 1 | Out of stock | Shipping within 2 weeks | € 0,86 | |||
| 2301457 C | 1/4 GAS | 14 | 22.5 | 6.5 | 15 | 90° | 1 | Out of stock | Shipping within 2 weeks | € 1,29 | |||
