Precleaner EZP-LS High Temp

The EZP-LS High-Temp is made from heavy-duty, powder-coated steel with a yellow High-Temp blade that works in temperatures up to 275°F (135°C) with spikes up to 325°F (164°C).

Commonly used in applications such as coke, clinker, cement, and asphalt.

Specifications:

• Maximum Belt Speed: 500 fpm (2.5 m/sec)

• Temperature Rating: Up to 275°F (135°C) with spikes to 325°F (164°C)

• Minimum Pulley Diameter: 6" (150 mm)

• ConShear™ LS blade sizes available: Belt Width Minus 2" (50 mm)

• Cleaner can also be retrofitted with Belt Width Minus 8" (200 mm) and Belt Width Minus 14" (350 mm) replacement blades

• Blade Height: 4.5" (115 mm)

• Usable Blade Wear Length: 2-3/8" (60 mm)

• Blade Material: Polyurethane (proprietary blend for abrasion resistance and long wear)

• Pole Diameter: 1-7/8" (48 mm)

• Belt Widths: 12" to 60" (300 to 1500 mm)


• Comes complete with universal mounting plates and tensioner

• Pole length: Belt width plus 30" (1350 mm)

• Horizontal clearance required: 3" (75 mm)

• Vertical clearance required: 6-1/2" (165 mm)
